S20 adopts professional 2D scan engine in combination with Bluetooth wireless data communication technology, supporting stable and reliable long distance of data communication. It easy compatible with Android and IOS smartphone.
Back to list >>
Powerful Endurance Ability
1200mAh rechargeable polymer lithium battery, make device could continuously work(1 scanning/s) for more than 15 hours with the fully charged.
Professional Scanning Module
High performance scanning module, easily decode all common 1D and 2D symbologies, have good performance in scanning fuzzy, low printed contrast rate and damaged barcode.
Convenient and Comfortable Operation
2.4GHz wireless technology Bluetooth connection, work well with Android and IOS smartphone.
Ultra-long Distance Transmission
Bluetooth (30 meters) long distance data transmission, supports automatic frequency modulation and inventory mode.
Industrial Grade Durability
IP54 industrial grade, and bear the height of 1.8m dropping and ground impact.
| Performance Parameters | |
| Image sensor | COMS |
| Resolution | 640x480 pixels |
| CPU | ARM 32 bit |
| Decode capability | 1D: UPC/EAN, UPC/EAN with supplements, ISBN/ISSN, Code 128, Code 39, Code 39 (Full ASCII), code 32, Interleaved 2of 5, Matrix 2 of 5, Codabar, MSI/Plessey, Chinese 2 of 5, China Postal Code, GS1 DataBar , etc. 2D: QR code, PDF417, Data Matrix, Maxicode, Aztec, etc. |
| Scan Angle | ±360°, ±60°, ±60°(Roll, Skew, Pitch) |
| Scan precision | ≥4mil |
| Print contrast | 20% |
| Depth of field | 20-500mm |
| Prompt mode | Buzzer, LED indicator light |
| Trigger mode | Manual, Continuous automatic scan |
| Memory | 350KB (Save 20,000 Barcode data) |
| Battery | 1200mAh (charging time is 3.0h) |
| Current | 60mA(standby), 160mA (working) |
| Work frequency | 2.4GHz |
| Data communication distance | 30m (Bluetooth) (open area) |
| Physical Parameters | |
| Over dimension | L X W X H (152.2x65.3x24mm) |
| Weight | 130g (include battery and exclude wire) |
| Charging cable length | 1.0m |
| Material | ABS+PC environmentally friendly materials |
Environmental Parameters | |
| Working temperature | -20°C to 50°C |
| Storage temperature | -40°C to 60°C |
| Anti-drop | Withstand drop from 1.8m to concrete floor |
| Humidity | 5% to 95% RH |
| IP grade | IP54 |
| Circumstance luminance | 0-100,000Lux |
