C8000 provides users wide field-of-view, which can quickly and easily scan all kinds of print barcode, merchandise code and mobile phone screen barcode. Super sensitive induction module for fast induction and fast reading barcode.
Back to list >>
Excellent Identification Ability
High performance scanning module, with superior wide field-of-view, omni-directional scanning capability.
Automatic interface detection
Enable the scanner to configure appropriate interface once connected, avoid the tedioustask of scanning programming
Convenient and Comfortable Operation
Ergonomics design to provide superior operation experience and boost work efficiency.
High Quality
Adopt high quality wires and inflaming retarding materials with the international standard, recyclable and practical shell to protect the device.
Industrial Grade Durability
IP54 industrial grade, no worry operate device in dust and moist circumstances.
| Performance Parameters | |
| Image sensor | CMOS |
| Resolution | 1280x1024 pixels |
| CPU | 32 bit ARM |
| Decode capability | 1D : UPC/EAN, Code 128, Code 39, Code 39 (Full ASCII), code 32, code 11, Interleaved 2of 5, Matrix 2 of 5, Discrete 2 of 5, Codabar, Chinese 2 of 5, China Postal Code, GS1 DataBar , etc. 2D: PDF417, Micro PDF417, QR code, Micro QR, Data Matrix, Aztec, etc. |
| Scan angle | ±360°, ±65°, ±70°(Roll, Skew, Pitch) |
| Scan precision | ≥3mil |
| Depth of field | 30-350mm(13mil UPC/EAN 100%, PCS=90%) |
| Print contrast | 20% |
| Prompt mode | Buzzer, LED indicator light |
| Interface | USB, USB-COM |
| Trigger mode | Auto-induction scanning |
| Setting method | Scan configuration barcode |
| Current and voltage | 160mA(standby), 270mA (working), 5VDC±10% |
| Physical Parameters | |
| Over dimension | L X W X H (151.5x153x84mm) |
| Weight | 540g |
| Material | ABS+PC environmentally friendly materials |
| Cable length | 1.8M |
Environmental Parameters | |
| Working temperature | -20°C to 50°C |
| Storage temperature | -40°C to 60°C |
| Anti-drop | 1.2m |
| Humidity | 5% to 95% RH |
| IP grade | IP54 |
| Circumstance luminance | 0-100,000Lux |
